Huahana Huahana
Kūlike 15 ʻīniha PCAP Capacitive Industrial Touch Panel
hoʻohālikelike o nā ʻāpana huahana
| inoa huahana |
Kūlike 15 ʻīniha PCAP Capacitive Industrial Touch Panel |
Brand |
Grahowlet |
| Hoʻohālike huahana | HX1501802 | Nui | 15 iniha |
| Ka Mahana Hana | -20degere ~70degere , He emi a like paha me 85%RH | IC hoʻoponopono | Cypress |
| Mahana Waihona | -30degere ~80degere , He emi a like paha me 85%RH | Nā Lae Paʻi | 10 helu |
| Ana Hoʻopuka | 365(W)×294.5(H)×2.9(D)mm | Olelo Hooholo | 1024×768 |
| Wahi Nānā | 306.4(W)×230.4(H)mm | Hana Hoopaa | Hoʻopili ʻia ea/Optical |
| Wahi Hana | 304.13(W)×228.1(H)mm | Palapala noi | Noi Hana Hana |
| Pūnaehana kākoʻo | Windows/Android/Linux Etc. | ʻAno Interface | IIC/USB |
| Palapala hōʻoia | 1 makahiki | Kapili | G+G |
| Voltage Mana | 3.3V | ʻO ke kukui | 600cd/m2 |
| ʻAlohilohi | ʻOi aku ma mua a i ʻole like me 85% | ʻOoleʻa ʻili |
ʻOi aku a i ʻole like me 6H |
10-POINT MULTI-TOUCH KOKO
E ʻike i ka hoʻomaopopo ʻana i nā ʻano manamana lima maʻemaʻe a pane loa me ka ʻenehana paʻi capacitive 10- kiko. ʻO ke kui ʻana no ka hoʻonui ʻana, ka hoʻololi ʻana i nā kiʻi, a i ʻole ka hoʻokō ʻana i nā kauoha lima -paʻakikī, hāʻawi kēia module hōʻike i ka launa pū ʻana me ka lauwili ʻole e hoʻonui ai i ka huahana a me ka hoʻopili ʻana o nā mea hoʻohana ma nā noi āpau.
KA WAI a me ka wai paʻakai pale ʻole i ka hoʻopā
Hoʻomakaukau ʻia e hana me ka hala ʻole i nā kūlana pulu a me ka haʻahaʻa, mālama kēia module paʻi capacitive i ka ʻike paʻi pololei ʻoiai ke uhi ʻia ka ʻili i ka wai, ua, a i ʻole ka wai paʻakai. He kūpono no nā ʻōnaehana hoʻokele kai, nā hale kūʻai waho, nā mea kanu meaʻai, a me nā wahi ʻē aʻe kahi e hiki ʻole ai ke ʻike ʻia ka makū.
NĀ MĀ KĀNĀWAI KAHIKI
Kākoʻo ka hiki ʻana i nā mīkina lima -ma -i nā mīkina lima o nā mea a pau. Hoʻopau kēia hiʻohiʻona i ka pono o nā mea hoʻohana e wehe i nā mea pale, e hōʻoiaʻiʻo ana i ka holo ʻole o ka hana ma nā hale hana, nā hale hana, nā hale mālama anu, a me nā wahi hana waho.
HIGH OPTICAL TRANSPARENCY ( ʻOi aku ma mua a i ʻole like me 85%)
E hauʻoli i nā hiʻohiʻona aniani-akaka me ka ʻoihana-alakaʻi ʻike maka o 85% a ʻoi aku paha. Mālama kēia i ka hōʻike ʻana i ka maʻiʻo-inā paha he kikokikona, kiʻi kiʻi, a wikiō paha-i ʻike ʻia a ʻoiaʻiʻo-i-kala, e hoʻonui ana i ka heluhelu a me ka hōʻemi ʻana i ke kaumaha o ka maka i ka wā hoʻohana lōʻihi.
ʻO Hangzhou Hongxiao Technology Co., Ltd. he ʻoihana ʻenehana -level kiʻekiʻe-ʻoihana i hoʻokumu ʻia ma Hangzhou, e paʻa ana ma mua o 30 mau palapala hōʻoia me nā patent invention a me nā lako polokalamu kope kope. Hoʻokomo nui ka ʻoihana i ka noiʻi, hoʻomohala, hana, a me ke kūʻai ʻana i nā pale paʻi capacitive, nā hōʻike LCD, nā modules capacitive touchscreen, nā ʻenehana pā serial port touchscreens, nā modula paʻi piha piha, nā papa hoʻokele interface, a me nā mea hana. Hoʻohana ka hui i kahi ʻoihana hana akamai no kēia manawa no-nā huahana hoʻopili mīkini. Hoʻokuʻu ʻia kāna mau modula touchscreen capacitive i nā tausani o nā mea kūʻai aku ma ka honua holoʻokoʻa a hoʻohana nui ʻia i nā kula e like me nā lāʻau lapaʻau, nā noi automotive, ka mana ʻoihana, nā keʻena hoʻoili, nā ʻōnaehana home akamai, nā mea hana akamai, palekana akamai, hoʻonaʻauao akamai, a me nā robotics akamai. Me ka ʻike nui ma ka ʻoihana-nā hoʻonā papahana kikoʻī, hiki i ka hui ke hāʻawi aku i nā ʻoihana loea, hoʻoponopono a me nā lawelawe ʻenehana i nā mea kūʻai aku ma nā ʻāpana like ʻole.
01
ʻIke waiwai
Me ka ʻoi aku o 10 mau makahiki o ka ʻoihana loea, ua hoʻokumu kā mākou hui iā ia inā he alakaʻi hilinaʻi i ka hoʻolālā, hoʻomohala ʻana, a me ka hana ʻana i nā -hana kiʻekiʻe capacitive touchscreens.
02
Nā Mīkini Kiʻekiʻe
ʻO ka ikaika o ka hale hana i hoʻohui ʻia e kākoʻo i nā ʻano like ʻole o ka capacitive touchscreen customization, me ke aniani substrate, flim base, optical adhesive (OCA), ITO ka uhi ʻana i nā mana hana waiwai āpau.
03
ʻenehana maikaʻi loa
Hāʻawi mākou i nā hāʻina hoʻopā capacitive kiʻekiʻe i manaʻo ʻia e kākoʻo ana i ka multi-touch, hana mīkina lima, a me ka hoʻohana ʻana i ke kaiapuni. Me ka hana piha OEM/ODM i kā mākou ʻenehana e hōʻoia i ka pololei, ka lōʻihi, a me ka ʻike mea hoʻohana maikaʻi loa ma waena o nā ʻoihana, nā lāʻau lapaʻau etc.
04
Hana Hana Kuʻuna
Hāʻawi mākou i ka lawelawe maʻamau OEM/ODM no nā pale paʻi capacitive - mai ke koho ʻana i nā mea maka (ke aniani substrate, ITO coating, OCA bonding) i ka hoʻolālā hoʻolālā, hoʻoponopono firmware, a me ka hoʻololi ʻana i ke kaiapuni.
| papahana Assessment | 1~2 mau lā hana |
| Nā papahana hoʻolālā | 2~3 mau lā hana |
| Hua kūʻai | 3 ~ 4weeks (Ma hope o ka ʻae ʻia ʻana o nā kiʻi) |
| Hoʻouna ʻana i ka hana nui | 4.3-5 mau pule |
| Ka hiki | 100k i kēlā me kēia mahina (10.1 iniha no ka ʻike) |
| hiki ke akamai | G+G/G+F+F, kaʻina hana pale Lamination piha (OCR/OCA), uhi uhi aniani ʻili lapaʻau e like me AR, AG, AP, etc. |
| Kākoʻo ʻenehana | Hāʻawi nā ʻenekini i nā lawelawe puka-i{1}}puka a i ʻole nā lawelawe komo mamao i loko o 24 mau hola |
| ʻO kahi kaulahao paʻa paʻa i hōʻoia ʻia no ka liʻiliʻi o 3 a 5 mau makahiki | |
| Hoʻokahi-makahiki palapala hoʻokō ma kā mākou huahana a pau | |
Hāʻawi kā mākou hui i ka ʻike e pili ana i ka hoʻolālā a me nā kikoʻī kikoʻī o kahi module display capacitive touch display module, wāwahi ʻia i ka papa ma ka papa:
1. Haʻihaʻi Layer (mai luna a lalo)
◦ Ke aniani uhi: ʻO ka papa pale waho loa o ka pā.
◦ ʻIke: ʻO ka papa -paʻi paʻa e ʻike i ka hoʻokomo ʻana o ka mea hoʻohana.
◦ Pākuʻi TFT: ʻO ka papa hōʻikeʻike aniani wai e hoʻopuka i ka hoʻopuka ʻike.
◦ Papa Tcon (Papa Mana Manawa): ʻO ka papa hoʻokele e hoʻoponopono i nā hōʻailona a hoʻokele i ka papa hōʻike.
2. Hoʻopilikino kikoʻī
◦ PCAP (Keaniani Uhi + Nani Hoʻopā):
◦ Nui, Hoʻopā IC, ʻano, waihoʻoluʻu, hōʻailona, mānoanoa, Interface, Structure, FPC (Flexible Printed Circuit)
◦ Papa Hōʻike TFT/OLED:
◦ Hoʻoholo, Luminance, Interface, Brand
◦ Papa Tcon:
◦ Papa hoʻokele HDMI/VGA, "IIC TO USB" bridge board, Papa hoʻololi no TFT, Serial Port Screen.
Hāʻawi kā mākou hui i kā mākou mea kūʻai aku i kahi kikoʻī kikoʻī o nā ʻāpana, nā hiʻohiʻona, a me nā mea hoʻohui o kahi module touch screen (TFT Bonded CTP):
1. Haʻihaʻi ʻāpana
◦ Pākuʻi Paʻi Module (TFT Bonded CTP): ʻO ka hui hōʻike hoʻopā piha.
◦ Lens uhi (Keaniani uhi):
◦ Nā hiʻohiʻona: Nā ʻano like ʻole me nā ʻokiʻoki i loaʻa; kākoʻo i ka paʻi kilika a me nā hōʻailona maʻamau; kūpono me nā maka aniani e like me AGC, Corning, CG; hiki ke mālama ʻia me AG (Anti-Glare), AR (Anti-Reflective), AF (Anti-Fingerprint), a i ʻole -pale pahū; nā koho mānoanoa mai 0.55mm a 6.0mm.
◦ Hoʻopaʻa i ka mea ʻike:
◦ Nā hiʻohiʻona: Aia nā mea waiwai i ke aniani, ke kiʻiʻoniʻoni, a me ke kiʻiʻoniʻoni-ma-kiʻiʻoniʻoni; mānoanoa mai 0.005mm a 1.1mm; nā ʻano FPC hiki ke hoʻololi ʻia; kākoʻo i nā hōʻailona IC pā e like me Cypress, Atmel Focaltech, Goodix, a me EETI; ʻO nā mea hoʻopili me IIC, USB, SPI, a me RS232.
◦ Hōʻike LCD TFT: ʻO ka papa hōʻike lalo.
◦ Hui: Loaʻa ma o Optical Bonding (OCA/OCR) a i ʻole nā kaʻina hana Frame Adhesion.
2. Nā ʻike hou aku
◦ Inā makemake ʻoe i ka USB interface, hiki iā mākou ke hāʻawi iā IIC i ka USB bridgeboard.
Huahana Huahana
Nā Hiʻohiʻona Huahana o ka Hōʻike Paʻi Paʻi
Hōʻike kēia kiʻi i ka hana nui a me nā hiʻohiʻona hana maʻamau o ka module hōʻike paʻi, me nā wehewehe penei:
1. Pili lima lima lima
Kākoʻo ka touchscreen i ka hoʻokomo pono ʻana ma o nā mīkina lima o nā mea āpau, ʻoiai me ka mānoanoa hui a hiki i 6mm.
ʻO nā ʻano mīkina lima i kākoʻo ʻia:
• Nā mīkina lima naylon/ Nā mīkina lima Latex/ Nā mīkina lima pulupulu
2. Wai/Brine/Aila Kū'ē no ka Paʻi
Paʻa mau ka hana paʻi i ka wā e ʻike ʻia ai ka pale a hoʻohana ʻia me:
• Wai ma'ema'e/Aila/ 5% wai pa'akai (brine)
3. 8mm Pahū Mānoanoa-Ke aniani uhi hōʻoia
Hiki ke hoʻolako ʻia ka hōʻike me ke aniani uhi wela 8mm mānoanoa, e hāʻawi ana i ke kūpaʻa kiʻekiʻe a me ka pahū-hana hōʻoia, me ka mālama ʻana i ka hana hoʻopā maʻamau.
4. Hoʻomaʻamaʻa i ka uhi aniani i koho ʻia (AG, AR, AF)
Kākoʻo ke aniani uhi i ʻekolu ʻano o nā pale hana e hoʻonui ai i ka ʻike mea hoʻohana a me ka lōʻihi:
• Lapaau -Glare (AG).
Hoʻololi i ke kukui pololei i kukui puʻupuʻu ma ka pale paʻi, hoʻopau i ke aniani-e like me nā hiʻohiʻona a hoʻemi ʻia ka ʻālohilohi.
• Lapaʻau -Reflective (AR).
Hoʻohui i kahi uhi e hōʻemi i ka mālamalama i ʻike ʻia ma ke aniani uhi, e hoʻohaʻahaʻa loa i ka noʻonoʻo ʻana o ka pale a hoʻomaikaʻi i ka ʻike ʻana i ka mālamalama o ka lā.
• Lapaʻau -Fingerprint (AF).
Hoʻopili i kahi uhi e hoʻonui ai i ka maʻalahi o ka ʻili, e hōʻemi i ka pale ʻana, nā kaha wai i koe, a me nā manamana lima. Hoʻonui kēia i ka manaʻo paʻi a me ka maopopo ʻike.
Palapala hōʻoia
Ua loaʻa i kā mākou capacitive touch screens nā palapala loiloi maka mua ma ka honua holoʻokoʻa, me nā helu 5-hōkū mau e hōʻike ana i kā lākou hana hilinaʻi, pane pane pololei, a me ka quailty bulid.
1. Laulā o nā huahana maʻamau (1.3 "a 65")
Hāʻawi mākou i nā hoʻonā IC touch versatile me ke kākoʻo koʻikoʻi no kahi ākea o nā noi ʻoihana, hoʻokō ʻia e nā lawelawe kūikawā a pilikino. Kākoʻo kā mākou hoʻonā ʻana:
• Hoʻopā ka hana me ka wai
• Hoʻopā i nā mīkina lima i hana ʻia me nā ʻano mea like ʻole
• Hoʻopā ma ke aniani uhi me ka mānoanoa a hiki i 20mm
2. Hiki ke hilina'i, -huahana ki'eki'e:
Hōʻike kā mākou huahana i ka maikaʻi paʻa, ke ola lōʻihi o ka lawelawe ʻana, a me ka hana kūʻē -kiʻekiʻe. Kākoʻo ʻia e kahi hui ʻenehana ikaika, hāʻawi mākou i nā koho huahana like ʻole, me nā papa hoʻoponopono maʻamau a me nā ʻāpana metala, e hoʻokō i nā koi kikoʻī o kāu papahana.
3. Touchscreen & hōʻike i hana hiki
Na Hana Hana Hou
Loaʻa iā mākou nā lumi hoʻomaʻemaʻe Papa 1000 & Papa 100, a me nā laina hana hoʻoheheʻe ʻakomi a me ka semi{2}}potting optical bonding. ʻO kēia mau mea e hiki ai iā mākou ke hāʻawi i nā kaʻina hana automation piha no nā pale paʻi a me nā hōʻike.
Makemake ʻoe iaʻu e hoʻohui i kēia i hoʻokahi, hui pū
Nīnau pinepine
Hiki iā ʻoe ke hāʻawi i ka lawelawe OEM?
-
ʻAe, hāʻawi mākou i nā lawelawe OEM a me ODM a hiki ke hana i nā huahana e pili ana i nā kiʻi āu e hāʻawi ai.
Pehea e hiki ai iaʻu ke hilinaʻi i ka maikaʻi o kāu huahana?
+
-
Loaʻa iā mākou ma mua o 10 mau makahiki o ka ʻike ma ka ʻoihana pale. Mai ke kūʻai ʻana i nā mea a hiki i ka hāʻawi ʻana i nā huahana, loaʻa iā mākou nā limahana ʻoihana ponoʻī a me nā kaʻina hana e pale aku ai i ka hopena maikaʻi. Ua ʻae ʻia kā mākou huahana e ROHS.
He aha kāu lawelawe ma hope o -kuai?
+
-
Inā pilikia kekahi, e loaʻa iā ʻoe kā mākou pane i loko o 24 mau hola. E hāʻawi koke ʻia ka hopena e kā mākou hui loea a ikaika.
He aha ke kauoha liʻiliʻi?
+
-
: ʻO kā mākou hui e pili nui ana i nā makana kūʻai nui, akā inā makemake ʻoe e kūʻai i hoʻokahi set, e ʻoluʻolu e lawe i kahi laʻana no ʻoe e nānā i ka maikaʻi a me ka hana. i ka manawa e hōʻoia ʻia ai ka laʻana, hiki iā mākou ke ʻae i kahi mauna liʻiliʻi o nā kauoha (ʻaʻohe palena palena) e hoʻokomo ʻia i ka hana a i ka manawa i hōʻoia ʻia ai, koi ʻia ka MOQ.
Pehea ka lōʻihi o ka manawa hōʻoia no kāu huahana?
+
-
ʻO ka manawa maʻamau 1 makahiki palapala hōʻoia me ka ʻole i hōʻino ʻia e ka poʻe hana e like me ka hoʻohana hewa ʻole.
